CP Plus 16Ch NVR 16× 2MP Dual Light Two-Way Audio Bullet Camera Combo with 2× Gigabit PoE Switch & 4TB WD Purple HDD

The CP Plus 16 channel dual light two-way audio combo price India positioning makes this a turnkey surveillance solution for Delhi NCR businesses needing complete coverage with audible deterrence and color night vision. If you are evaluating network video recorders for multi-camera deployments for your Delhi NCR premises, this bundle ships with a CP Plus 16-channel AI NVR, sixteen CP Plus 2MP dual light bullet cameras with built-in microphones and speakers, a pre-installed 4 TB surveillance-rated hard drive with 3-year manufacturer warranty, and two CP Plus 8-port Gigabit PoE switches. At Thencix in Nehru Place, we physically verify every camera, test two-way audio clarity across all 16 channels, confirm NVR discovery, and supply full GST invoicing so your finance team can claim input tax credit. The dual light technology pairs IR night vision with warm light supplement for color footage in darkness, while the built-in speakers let security teams speak directly to intruders or delivery personnel from the monitoring station. Every camera carries STQC approved compliance certification, BIS certification, and CE marking per the CP Plus India datasheet, making this combo eligible for government tenders and institutional bids. Every unit ships with the GST invoice required for PAN-based business purchases. Contact Thencix on WhatsApp at +91 9891150949 for same-day quotations and on-site survey scheduling.

Product Overview and Two-Way Audio Surveillance Value

The CP Plus 16-channel AI NVR at the center of this combo is built on an industrial-grade embedded processor running Embedded LINUX, with H.265, Smart H.264+, and Instastream compression support. Instastream algorithms reduce bandwidth consumption by up to 70 percent compared with standard H.265 through Intelligent Region Perception, allocating higher bitrates to moving objects and lower bitrates to static backgrounds. For a Gurgaon logistics hub recording 16 channels continuously, this translates to approximately 30 to 40 Mbps total storage throughput instead of 80 to 100 Mbps with conventional codecs, directly reducing hard drive wear and extending the 4 TB disk’s retention period.

Per CP Plus India official documentation, this NVR provides 80 Mbps incoming bandwidth, 80 Mbps storage bandwidth, and 60 Mbps forwarding bandwidth. A typical deployment of sixteen 2MP dual light cameras at 15 fps using H.265 consumes approximately 32 to 48 Mbps, leaving 32 to 48 Mbps of headroom for bitrate spikes during low-light scenes when noise raises encoding complexity. The decoding capability supports simultaneous playback of six 1080p channels at 30 fps, sufficient for security supervisors reviewing multiple angles during incident reconstruction. The NVR also provides 1-channel RCA audio input and 1-channel RCA audio output for two-way talk, enabling the security guard to speak through the NVR to any camera with a built-in speaker across the network.

The recorder measures 260 mm wide, 232.7 mm deep, and 47.6 mm tall, weighing 0.81 kg without the hard drive. During our Nehru Place bench testing, the metal chassis maintained stable operation at 40 degrees Celsius ambient with the 4 TB drive spinning continuously, though we recommend rack mounting with 50 mm clearance on all sides for airflow in non-climate-controlled security rooms. The single RJ-45 10/100 Mbps Ethernet port connects to the network infrastructure — in this combo, the two PoE switches cascade through their Gigabit uplink ports, with the NVR hanging off one switch or a central router. While the 100 Mbps port handles 16-channel 2MP streams comfortably, sites planning future 4MP or 8MP upgrades should consider a Gigabit-equipped NVR model; contact Thencix on WhatsApp for upgrade paths.

2MP Dual Light Bullet Cameras with Built-in Two-Way Audio

The sixteen cameras in this bundle use 1/2.7-inch 2MP PS CMOS sensors delivering 1920 × 1080 resolution at 25/30 fps through a 3.6 mm fixed lens with F1.4 aperture. The F1.4 large aperture captures approximately 40 percent more light than the F2.0 lenses common on entry-level bullets, producing cleaner low-light footage before the illuminators even activate. The horizontal field of view spans 86 degrees, covering warehouse aisles, school corridors, and factory perimeters without requiring multiple cameras per zone. At 350 grams and 196.74 mm in length, the metal and plastic casing feels substantial during wall mounting and dissipates heat efficiently during Delhi summers when ambient temperatures exceed 40 degrees Celsius.

The dual light system pairs 2 infrared LEDs for 30 meters of monochrome night vision with 2 warm light LEDs for 30 meters of color night vision. Smart illumination technology automatically selects the optimal mode based on ambient conditions — IR mode for discreet surveillance where light pollution is undesirable, and warm light mode for color identification where vehicle colors, clothing details, and facial tones matter. For a Delhi retail chain investigating after-hours break-ins, the warm light captures the exact shade of a perpetrator’s jacket and the color of a getaway vehicle — details that standard IR cameras lose to monochrome conversion. The 0.001 lux minimum illumination in color mode and 0.0001 lux in black-and-white mode ensure the camera produces usable footage under minimal street lighting.

Each camera integrates a built-in microphone and built-in speaker, enabling true two-way audio communication over the network. The security supervisor at a Noida factory can speak directly to a delivery driver at the loading dock camera without leaving the monitoring room. The built-in siren can be activated remotely through the iCMOB or gCMOB app to deter trespassers in real time. The G.711a, G.711Mu, PCM, G.726, and AAC audio compression options ensure compatibility with the NVR’s audio processing while maintaining intelligible speech at low bitrates. Echo cancellation prevents feedback when the microphone and speaker operate simultaneously in confined spaces. The triple-stream output provides a main stream at 2MP for local recording, a sub-stream at 720p or D1 for remote viewing over Jio Fiber or Airtel Xstream connections, and a third stream for mobile app access.

Intelligent Motion Detection and Cyber Security for Indian Enterprises

The intelligent motion detection engine on each camera classifies humans and vehicles separately from environmental noise, enabled by default across all 16 channels. Unlike standard pixel-change detection that triggers during monsoon rains, dust storms, and insect swarms, the algorithm recognizes the silhouette of a person climbing a fence or a vehicle entering a restricted zone. For a Faridabad manufacturing unit, this means the NVR records and pushes alerts only for relevant targets, eliminating the storage waste and notification fatigue caused by stray dogs, wind-blown plastic, and shifting shadows.

The smart search function works with intelligent motion detection to isolate all human or vehicle-triggered events across 16 channels in under 60 seconds, transforming incident investigation from hours of manual scrubbing into targeted clip review. The 3D digital noise reduction cleans grain from low-light footage during dusty pre-monsoon evenings when atmospheric haze reduces effective illumination. The 128 MB RAM and 128 MB ROM on each camera support on-board analytics without relying on cloud processing, ensuring detection continues even when the 4G or fiber link experiences monsoon-related outages.

Cyber security hardening includes AES 256-bit encryption for video streams, configuration encryption, trusted execution, digest authentication, security logs, WSSE account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, and trusted boot. For government contractors and PSU vendors in Delhi handling sensitive project documentation, these layers satisfy baseline compliance requirements for data protection. The STQC approved compliance report, BIS certification, CE marking, FCC compliance, and RoHS adherence are all documented on the CP Plus India datasheet, making these cameras eligible for e-tender submissions across Indian states. When your team needs additional IP cameras for future expansion, Thencix stocks compatible 2MP and 4MP dual light models with identical certification profiles.

Dual 8-Port Gigabit PoE Switches and Network Topology

This combo includes two CP Plus 8-port Gigabit PoE switches, each providing 8 Gigabit PoE ports and 2 Gigabit uplink ports with a 96-watt total PoE budget. The store-and-forward architecture delivers 20 Gbps full-duplex switching capacity, ensuring that 16 simultaneous 2MP streams do not congest the backbone. IEEE 802.3af and 802.3at compliance guarantees compatibility with the cameras’ PoE power requirements, while the 30-watt maximum per port leaves room for future upgrades.

Per the CP Plus India datasheet, each camera draws a maximum of 13.1 watts over PoE when H.265, WDR, IR intensity, warm light deterrence, and speaker are all active simultaneously. Sixteen cameras at this peak load consume 209.6 watts total, exceeding the 192-watt combined PoE budget of the two included switches. In practice, however, not all cameras activate warm light and speaker simultaneously — a typical mixed load with 8 cameras in IR mode at 4 watts and 8 cameras in warm light mode at 10 watts consumes approximately 112 watts, well within the 192-watt budget. For sites expecting simultaneous peak load on all channels, Thencix recommends verifying power allocation during commissioning or upgrading to higher-wattage switches.

The network topology for this 16-camera deployment places 8 cameras on each switch, with the switches connected via their Gigabit uplink ports in a daisy-chain or star configuration. The NVR’s 100 Mbps Ethernet port connects to one switch or to a central router that aggregates both switches. In a typical Noida factory installation, Switch A serves the production floor with 8 cameras, Switch B serves the warehouse and loading dock with 8 cameras, and both uplink through a Gigabit router to the NVR in the security room. The VLAN support on the switches segments camera traffic from office Wi-Fi and ERP systems, preventing bandwidth contention during Tally ERP backups or Zoho Books synchronization. Each switch includes ESD protection and 2 kV surge protection on RJ45 ports, tolerating voltage fluctuations common in Indian industrial zones without requiring separate UPS units for each switch.

4TB Surveillance Storage and Three-Year Drive Warranty

The included 4 TB surveillance-rated hard drive is pre-installed and formatted for 24/7 write workloads, and it carries a 3-year manufacturer warranty. At 16 channels of 2MP H.265 footage using Instastream at approximately 2 to 3 Mbps per channel, the total storage consumption is 32 to 48 Mbps. A 4 TB drive provides approximately 15 to 20 days of continuous recording at this bitrate, or 30 to 45 days with motion-triggered recording enabled through the NVR’s schedule settings. For a Faridabad manufacturing unit operating two 12-hour shifts, this retention exceeds the 30-day minimum most Indian commercial insurers require for theft and liability coverage.

The NVR supports one SATA III drive up to 16 TB, meaning the 4 TB disk can be upgraded without replacing the recorder. The dual USB 2.0 ports enable quick backup of incident footage to external drives for police handover or insurance documentation. For CA firms in Connaught Place auditing client security infrastructure, the NVR’s multi-user account limit allows multiple auditors to access footage simultaneously without additional VMS licenses. The 3-year drive warranty provides peace of mind for continuous-write environments where consumer desktop drives typically fail within 12 months.

Key Features

• 16-Channel AI NVR with Instastream and Two-Way Talk: H.265 and Smart H.264+ compression reduce storage consumption by up to 70 percent, with 80 Mbps incoming bandwidth and 1-channel RCA two-way audio for speaking to any camera location from the monitoring station.
• 16× 2MP Dual Light Bullet Cameras with Built-in Mic and Speaker: 1/2.7-inch PS CMOS, 1920×1080 at 30 fps, F1.4 large aperture, 30-meter IR plus 30-meter warm light smart illumination, and true two-way audio with echo cancellation on every channel.
• STQC Approved Compliance with BIS and CE Certification: Every camera carries STQC approved compliance, BIS certification, and CE marking per CP Plus India datasheet, qualifying the combo for government tenders and institutional bids.
• Dual 8-Port Gigabit PoE Switches with 192W Total Budget: Two switches provide 16 Gigabit PoE ports with 96 watts each, 20 Gbps switching capacity, VLAN support, and 2 kV surge protection for reliable camera power and data across large premises.
• 4TB Pre-Installed Surveillance HDD with 3-Year Warranty: The NVR and cameras carry 2-year CP Plus carry-in warranty; the 4 TB drive carries 3-year manufacturer warranty. Every purchase includes GST invoice for PAN-based input tax credit.

Technical Specifications

Package Contents

• CP Plus 16-Channel AI NVR unit (1×)
• CP Plus 2MP Dual Light Bullet Camera with built-in mic and speaker (16×)
• CP Plus 8-Port Gigabit PoE Switch (2×)
• 4 TB Surveillance-Rated Hard Disk Drive, 3-year warranty (pre-installed in NVR)
• NVR power adapter (12V DC, 1.5A)
• Camera mounting brackets with screws and wall anchors (16 sets)
• Switch power cables (2×)
• Rack mount ears for NVR (1 set)
• Quick start guides and safety documentation
• NOT INCLUDED: HDMI cable, VGA cable, monitor, Ethernet patch cables (18+ required), 4G router, UPS unit, mounting poles, conduit, cable trays

Cross-sell note: Need Ethernet cables, a monitor, or a UPS for this deployment? Thencix stocks enterprise UPS systems and high-speed cables and adapters for complete installation.

Ideal Use Cases for Indian Businesses

Manufacturing Facility and Factory Floor Coverage: A Faridabad automotive component supplier installs all 16 cameras across the production floor, raw material storage, finished goods warehouse, and loading dock. The dual light cameras capture color footage at the loading dock under sodium vapor lights, while the built-in speakers let the supervisor warn forklift operators about safety violations without leaving the control room. The two switches segment production floor cameras from warehouse cameras on separate VLANs, preventing network congestion when the ERP system runs Zoho Books backups during shift changes. The 4 TB drive retains 30 days of motion-triggered footage, satisfying the factory’s insurance auditor.

Educational Institution Campus Safety: A Delhi NCR school deploys 16 cameras across main gates, corridors, playgrounds, cafeteria, and parking areas. The STQC certification qualifies the installation for government education department grants. The two-way audio allows the principal to address visitors at the main gate directly from the administrative office, while the built-in siren deters unauthorized entry after hours. The intelligent motion detection filters out false alarms from birds and squirrels during morning assembly, sending push notifications to the iCMOB app only when unauthorized personnel enter restricted zones. The NVR’s multi-user account limit allows the principal, security agency, and PTA representatives to access live feeds from separate devices.

Retail Chain and Mall Security: A Connaught Place electronics retailer with a 15,000 sq ft showroom uses 12 cameras for floor coverage and 4 cameras for the stockroom and back entrance. The warm light mode captures the exact shade of clothing worn by shoplifters and the license plate colors of vehicles at the rear loading bay — details that standard IR cameras lose to monochrome conversion. The two-way audio lets the loss prevention officer challenge suspicious individuals in real time through the camera speaker, often preventing theft before it occurs. When your team needs additional IP cameras for future expansion, Thencix stocks compatible 2MP and 4MP dual light models.

Warehouse and Logistics Hub Monitoring: A Gurgaon-based e-commerce fulfillment center monitors 16 zones including inbound sorting, outbound packing, cold storage entry, and perimeter fencing. The -40 to +60 degree Celsius camera rating handles the cold storage ante-room at 5 degrees Celsius and the unshaded rooftop perimeter at 50 degrees Celsius equally. The 30-meter IR range covers the 25-meter-wide loading yard, while the built-in microphones capture verbal instructions during forklift operations for incident reconstruction. The two PoE switches mount in separate electrical rooms on opposite ends of the warehouse, minimizing cable runs and installation labor.

Why Buy from Thencix

• 2-Year CP Plus Carry-In Warranty on NVR and Cameras: Thencix supplies original CP Plus units with manufacturer warranty coverage verified from official India documentation. For warranty claims, retain your GST invoice and contact our Nehru Place support team for guidance through the CP Plus service center process.
• 3-Year HDD Warranty with GST Invoice: The pre-installed 4 TB surveillance drive carries a 3-year manufacturer warranty. Every purchase includes a proper GST bill for your business accounting and PAN-based input tax credit claims.
• Pre-Dispatch Channel Verification and Audio Testing: Thencix powers on every camera, verifies NVR discovery across all 16 channels, tests two-way audio clarity and speaker volume, confirms PoE port allocation on both switches, and checks HDD SMART status before shipping.
• Same-Day Dispatch from Nehru Place: Orders confirmed before 3 PM ship same day to Delhi, Noida, Gurgaon, and Faridabad via our local logistics partners. Need installation guidance, cable routing advice, or iCMOB/gCMOB app setup? WhatsApp +91 9891150949.
