CP Plus CP-UNC-TC41L5C-VMD-LQ 4MP Dual Light Bullet Camera 50m

The CP Plus CP-UNC-TC41L5C-VMD-LQ is a 4MP Dual Light fixed-lens bullet camera from CP Plus’s illumax series, designed for outdoor surveillance installations where the camera position and coverage angle are defined at the time of installation and do not require remote adjustment. It delivers 50 metres of IR illumination for covert monochrome night vision and 30 metres of warm white light for full-colour after-dark footage — both operating simultaneously or independently, controlled via the camera interface or NVR. The fixed 3.6mm lens (with 2.8mm and 6mm options available) provides a wide 84° horizontal field of view suited to open outdoor areas, parking lots, building approaches, and perimeter walls. For buyers across Delhi NCR looking for a cost-effective outdoor IP bullet camera with dual light technology, the CP-UNC-TC41L5C-VMD-LQ offers the full CP Plus illumax dual-light feature set — Starlight sensitivity, IVS analytics, AES-256 cybersecurity, STQC approval, and IP67 protection — in a fixed-lens form factor at a more accessible price point than motorized varifocal equivalents.

Overview of the CP Plus CP-UNC-TC41L5C-VMD-LQ

The CP-UNC-TC41L5C-VMD-LQ sits within CP Plus’s illumax camera range — a line specifically designed around dual-illumination technology combining IR and warm light in a single housing. The model designation breaks down as: TC = bullet form factor, 41 = 4MP, L5C = fixed lens, 50-metre range tier, VMD = Video Motion Detection with IVS intelligence, LQ = dual light (L) standard variant (Q). The camera uses a 1/2.7-inch 4MP PS CMOS image sensor with effective pixels of 2688 × 1520, recording at maximum 4MP resolution at up to 25/30fps in PAL or NTSC mode. An alternate 2560 × 1440 mode at 1–25/30fps provides a widescreen aspect ratio option for installations using 16:9 monitor setups. RAM and ROM are both 128MB — the same platform as other CP Plus illumax cameras in this range, ensuring stable simultaneous IVS processing, quad-stream encoding, and edge recording to SD card.

The key distinction between this model and the motorized varifocal CP-UNC-TC41ZL6C-VMD-LQ is straightforward: the TC41L5C-VMD-LQ uses a fixed lens rather than a motorized zoom. This makes it the right choice when the installation position is firmly decided, the required angle is known, and the budget benefits from not paying for motorized adjustment that will never be used. It is also 40 grams lighter (720g versus 760g) and draws lower maximum power (6.1W versus 10.2W at 12VDC with all features active), making it slightly more energy-efficient over the long run in a high-camera-count installation.

Dual Light Technology — 50m IR and 30m Warm Light

The CP-UNC-TC41L5C-VMD-LQ uses 2 dedicated IR LEDs and 2 dedicated warm light LEDs — four illuminators in total, with IR and warm light operating as separate elements rather than the multi-core combined LED design found in the higher-end TC41ZL6C model. IR coverage extends to 50 metres, providing covert monochrome illumination invisible to the human eye — suitable for installations where the presence of active lighting must not be visible, such as residential perimeter walls, hospital external areas, and locations near sleeping quarters. Warm light extends to 30 metres, producing full-colour footage in complete darkness by flooding the scene with visible white light. This 30-metre warm light range is appropriate for close-to-medium range colour capture at gates, building entries, car parks, and shop fronts where the camera is mounted 5–15 metres from the subject.

Smart IR is supported, meaning the camera automatically adjusts IR intensity based on the proximity of objects in the scene — preventing IR overexposure (the white-out effect common on nearby walls or a person walking close to the camera) that fixed-intensity IR cameras cannot handle. Day/Night modes include Auto (ICR), Colour, and Black and White — in Auto mode the motorised IR cut filter (ICR) engages as the scene darkens, ensuring true colour reproduction during the day and maximum sensor sensitivity at night without colour cast from IR wavelengths affecting the image.

Starlight Sensitivity — Colour at 0.001 Lux

The Starlight-rated sensor reaches 0.001 lux minimum illumination in colour mode and 0.0001 lux in black and white, meaning the camera captures usable colour footage in environments lit only by distant street lamps, shop signage, or ambient urban glow — before IR or warm light assistance is even needed. This is particularly valuable in mixed urban-residential areas across Delhi NCR where street lighting levels vary significantly from one colony to the next, and where a camera that switches prematurely to monochrome IR mode loses the colour evidence — clothing, vehicle paint, signage — that investigators and security teams most rely on. With 0 lux capability when IR is activated, the camera maintains a clear, detailed image in total darkness, such as inside a covered parking structure or a compound after power cut.

Lens Options — 3.6mm, 2.8mm, and 6mm Fixed

The standard configuration ships with a 3.6mm fixed lens providing a horizontal field of view of 84°, vertical field of 42°, and a diagonal of 101° — the most commonly specified angle for general outdoor surveillance covering entrances, walls, and open areas at distances of 5 to 20 metres. The DORI (Detection, Observation, Recognition, Identification) distances at 3.6mm are 85.4 metres (detection), 34.2 metres (observation), 17.1 metres (recognition), and 8.5 metres (identification). For installations requiring a wider angle — such as monitoring a full car park bay or a wide forecourt — a 2.8mm lens is available as an option, widening the horizontal field to 107° with a DORI identification distance of approximately 5.5 metres. For narrower, longer-range applications — a lane, a corridor exit, or a cashier counter viewed from a distance — a 6mm lens is available, narrowing the field to 54° horizontal and extending DORI identification to around 14 metres. Buyers should specify the lens option required at the time of purchase; Thencix can advise on the correct lens for your specific installation point based on a simple measurement of the distance and width of the area to be covered.

IVS Analytics — Tripwire, Intrusion, and SMD

The CP-UNC-TC41L5C-VMD-LQ includes the same IVS perimeter protection suite as the rest of the CP Plus illumax range: Tripwire (alert when a target crosses a virtual line in a defined direction), Intrusion (alert when a target enters or exits a defined polygon zone), and SMD (Smart Motion Detection — classifies detected motion as human or vehicle, discarding weather, shadows, and ambient movement from triggering false alarms). Four configurable rectangular motion detection zones, four privacy mask areas, and four ROI (Region of Interest) areas for bandwidth prioritisation are all included. The camera supports smart search with a compatible CP Plus Smart NVR, enabling rapid post-event video retrieval filtered by event type — significantly reducing the time needed to review footage across multiple cameras after an incident. For installations using multiple CP-UNC-TC41L5C-VMD-LQ cameras, pairing with the CP Plus 32-channel 4K AI NVR at Thencix gives access to NVR-side perimeter protection and SMD Plus for the full channel depth.

Cybersecurity, Certifications, and Edge Storage

The CP-UNC-TC41L5C-VMD-LQ carries the full CP Plus CTC (Trusted Core Technology) cybersecurity architecture: AES-256 encryption, configuration encryption, trusted execution, TLS Version 1.2, HTTPS, digest authentication, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, trusted firmware upgrade, and trusted boot. STQC approval and BIS certification make this camera directly eligible for government and Smart City surveillance tenders that mandate Indian government-certified equipment. ISO 9001:2015 and ISO 20000-1:2018 certifications round out the quality management picture alongside CE, FCC, and RoHS compliance. Micro SD edge storage up to 512GB is supported for standalone operation without an NVR; SFTP is also supported for network-based file storage. The operating temperature range of -40°C to +60°C is noteworthy — it exceeds the -30°C lower limit of the motorized varifocal equivalent and covers even extreme cold-chain or hill-station deployments across India’s varied climate zones.

Key Features

• 4MP Dual Light Bullet — 50m IR and 30m Warm White Light: 2 IR LEDs + 2 warm light LEDs provide covert monochrome coverage to 50 metres and full-colour visible-light coverage to 30 metres; Smart IR prevents overexposure on nearby subjects; switchable per scene or schedule via NVR interface.
• 3.6mm Fixed Lens, F1.4 Aperture, Starlight 0.001 Lux: Wide 84° horizontal field of view at F1.4 maximum aperture; DORI identification at 8.5 metres; 2.8mm (107° wide) and 6mm (54° narrow) lens options available — specify at order; Starlight sensor delivers colour footage before IR assistance is needed.
• IVS Tripwire, Intrusion, SMD + Smart Search: Perimeter protection with human/vehicle classification across all 4 IVS zones; Smart Motion Detection filters false alarms from weather and ambient movement; works with CP Plus Smart NVR for event extraction and smart playback.
• STQC + BIS Certified, CTC Cybersecurity (AES-256, TLS 1.2): Government tender-ready with STQC approval; full CP Plus Trusted Core Technology stack including video encryption, trusted boot, and OTA firmware upgrade; IP67 weatherproof metal body with optional IK10 vandal resistance.
• -40°C to +60°C Operating Range, 512GB Edge Storage, PoE: Widest operating temperature in its class; supports standalone micro SD recording up to 512GB; PoE 802.3af for single-cable installation; basic power draw of just 2W (12VDC) / 2.6W (PoE) — efficient for large multi-camera deployments.

Technical Specifications

Package Contents

• CP Plus CP-UNC-TC41L5C-VMD-LQ camera unit — 1
• Mounting hardware (screws, anchors) — as included
• Waterproof connector — 1
• Quick start guide — 1

Not included: Micro SD card (up to 512GB, sold separately), PoE switch or 12VDC power adapter, network cable, NVR. The 2.8mm and 6mm lens variants are available as separate configurations — confirm the required focal length at the time of ordering. For multi-camera outdoor installations, the CP Plus 24-port Gigabit PoE switch delivers single-cable power and data to up to 24 cameras from one unit.

Ideal Use Cases for Indian Buyers

The CP-UNC-TC41L5C-VMD-LQ is optimised for installations where the camera mounting point, coverage angle, and subject distance are all defined and fixed — the most common scenario in the majority of commercial and residential surveillance projects across Delhi NCR. Residential housing societies in Dwarka, Rohini, Vasundhara, and Noida Extension use this camera type at their compound gates and parking lots, where a 3.6mm lens from a 4–6 metre mounting height covers an 8–12 metre wide area cleanly and warm light at 30 metres handles the majority of vehicle and pedestrian activity at the gate. Retail shops in markets like Karol Bagh, Lajpat Nagar, and Janakpuri use the 3.6mm version for shop fronts and cash counters, where the wide-angle coverage means a single camera captures the full width of a typical Indian shop interior or gali-facing facade. Schools and colleges in NCR deploying CCTV under Central or State government schemes benefit from the STQC certification, which satisfies tender compliance requirements without any additional documentation from the buyer’s side.

For buyers who have already installed or are planning to install the CP-UNC-TC41ZL6C-VMD-LQ motorized version at certain locations, the TC41L5C-VMD-LQ is the natural companion camera for fixed-angle positions on the same site — maintaining brand consistency, the same NVR compatibility, and the same IVS feature set at a lower unit cost. The only trade-offs versus the motorized model are the fixed lens (no post-installation zoom adjustment), the 30-metre warm light range (versus 60 metres on the ZL6C), and the 50-metre IR range (versus 60 metres) — all acceptable for well-planned installations with known camera positions. What the TC41L5C gains is a lower maximum power draw, a wider operating temperature floor at -40°C, and a simpler, more compact installation profile.

Why Buy from Thencix

• Authorised CP Plus dealer at 109B Osian Building, 12 Nehru Place, Delhi 110019 — available for walk-in comparison between fixed and motorized lens models before purchase
• GST invoice on every sale — eligible for input tax credit; STQC-compliant for government project procurement
• Cash on Delivery for Delhi, Noida, Gurugram, Faridabad; pan-India shipping available
• Pre-sales lens selection advice — Thencix can recommend the right focal length (2.8mm / 3.6mm / 6mm) based on your camera mounting height, distance, and coverage width — WhatsApp +91 9891150949
• Post-purchase support: warm light vs IR scheduling, IVS rule setup, SD card formatting, iCMOB/gCMOB remote access configuration

Check stock or get a site-specific lens recommendation — WhatsApp +91 9891150949

CP Plus CP-UNC-TC41L5C-VMD-LQ — Frequently Asked Questions
